Ozne Aging Test Chamber

Home/Weathering Test Chambers/Ozne Aging Test Chamber
Ozne Aging Test Chamber 2017-04-14T07:01:41+00:00

Project Description

Ozne Aging Test Chamber is suitable for aging cracking test of non-metal materials and organic materials……

Description

Ozne Aging Test Chamber is suitable for aging cracking test of non-metal materials and organic materials(such as coatings,plastics,paintings,rubber products). Ozone content in the atmosphere is very low,but it is the main factor of organic materials aging. Ozone aging test chamber simulates and strengthens the ozone condition in the atmosphere, get approximate to actual use or reproduction of the test results in a short time.

Corresponding standard

  • JIS K 6259
  • ISO1431
  • ASTM D1171
  • ASTM D1149
  • DIN53509
  • GB/T 13642
  • GB/T 7762-2003

Detailed pictures

France Tecumseh compressor

France Tecumseh compressor

Test zone

Test zone

  • With Ozone generator
  • Automatic control and supply ozone gas
  • Temperature range 0℃ to 70℃
  • Ozone concentration from 0~1000PPHM(Adjustable)
  • LCD touch screen temperature controller
  • Equipped with sample holders
  • France “Tecumseh” fully hermetic refrigeration compressor

Model

JYOL-100

JYOL-125

JYOL-150

Internal Size(W*D*H,MM)

450*450*500

500*500*500

500*600*500

Model

JYOL-225

JYOL-500

JYOL-800

Internal Size(W*D*H,MM)

500*600*750

700*800*900

800*1000*1000

Temperature Range

0°C ~ 70 °C

Temperature Fluctuation

± 0.5°C

Temperature Uniformity

≤ ±2℃

Cooling Rate

Ambient temperature to 0°C wthin 50 min(nonlinear)

Ozone Concentration

0~1000PPHM (Adjustable)

Ozone Concentration Bias

± 10%

Ozone Source

Ozone generator

Sensor

Import high precision ozone concentration sensor

Controller

LCD touch screen temperature controller

Heater

U type nickel alloy heater

Timing Range

0~999 hours

Air Flow Speed

12~16mm/S

Ozone Output

3.5g/h

Refrigeration System

France “TECUMSEH” fully hermetic refrigeration compressor

Sample holder rotate speed

1r/min(adjustable)

Supply Voltage

AC 380V·50HZ
